Compact and powerful for breweries with brew sizes of up to 130 hectolitres

Modular brewing systems can be perfectly tailored to the needs of craft brewers. The key here is to combine flexible brewing processes and brew sizes with the often very limited space available. Steinecker CombiCube is a brewery concept for cold wort volumes of 50 to 130 hectolitres per brew.

At a glance

Compact layout for the brewhouse with a frame construction with two to six vessels for all process steps
Fermentation tanks and different options for beer treatment for the cold area
Standardised modules for utilities and CIP system
Automated processes are combined with manual intervention options for individually crafted beers

Brochure Steinecker CombiCube

1.07 MB, .pdf

The right equipment for every brewery

* Or cereal cooker

Example: 60 hl brewing plant, 8 brews per day, 12°P, infusion

Grist mill with 4 rollers

Grist milling capacity 800 kg/h with grist silo for 1,300 kg
Mashing-in output 6,500 kg/h

Mash tun

Maximum mash volume 44 hl, heating rate 1.0 K/min
Side wall and base heating for the mashing process
Pillow plate technology for low thermal impact
Optional: EquiTherm for regenerative power supply

Lauter tun

Lautering surface 7.07 m², false bottom load 183 kg/m²
Automatic lautering process for first wort and sparging wort with manual dosing of additives and disposal of spent grains

Brewkettle

External boiler with 326 kW
Optional: Vapour condenser with energy storage system
Up to 3 hops dosages of 6 kg each

Whirlpool

Trub tank (optional):, two-stage wort cooler, wort aeration with air or oxygen, wort pre-cooling (optional)

Example: 60 hl brewing plant

Yeast cellar

Yeast propagation with usable capacity of 6.8-24.1 hl
Yeast storage with usable capacity of 2.13-5.41 hl

Fermenting cellar

Usable capacity: 60, 120, 180 and 240 hl
Coolant: glycol water -4 °C
Extract breakdown: 3 °P per 24 h
Cooling:
- 24 hours from + 20 °C to + 4°C
- 48 hours from + 4 °C to + -1 °C
Manual filling of fermentation tank and bright beer tank
Volumes measured via mobile inductive flow rate measurement
Automatic temperature regulation, mechanical pressure regulation
Manual lost cleaning

Example: 60 hl brewing plant

Beer cooler, filter and centrifuge

Cooling medium, beer cooler: Glycol water -4°C, with a cooling rate of + 8°C to - 1°C
Filter aid: kieselguhr or alternative filter aids
Process water centrifuge (as per the manufacturer’s specifications)
Manual operation of the modules with performance data set up to match the tank size

CIP cleaning

Design as single-tank CIP, pre-piped four-tank CIP or free-standing four-tank CIP
Usable capacity:
- CIP system in brewhouse 25.2 hl
- CIP system in cellar 16.8 hl
Capacity of heat exchanger in brewhouse 145 kW, in fermenting cellar and storage cellar 58 kW
Hot or cold cleaning with manual or automatic function, depending on design

Example: 60 hl brewing plant

–	Output:	Cooling	118 kW for 0-4 brews per day
			134 kW for 5-8 brews per day
		Compressed air	35 Nm³/h for 0-4 brews per day
			70 Nm³/h for 5-8 brews per day
		Steam	Steam amount 1,170 kg/h
–	Automatic, self-controlled operation for cooling plant, air compressor and steam generator, plus manual operation of CO₂ supply and D/A water system
–	Supply via mains electricity supply for cooling system and air compressor, plus optionally via mains electricity supply or gas supply for steam generator; CO₂ supply via integration of CO₂ canisters

Technology – utilities and energy recovery

EquiTherm recuperates the thermal energy of the wort boiler and uses this to supply the mashing process.

Benefits to you

Optimum flexibility

You can flexibly combine the modular components as required to put together your own perfectly tailored brewery.
This individual combination of modules allows the CombiCube to stand out with low space requirements.
